20MHz 40MHz CPE WiFi Router CPE 4G Wireless Router Wan / Lan Port

Name: 20MHz 40MHz CPE WiFi Router CPE 4G Wireless Router Wan Lan Port
Brand: KINGTECH
Price: 1 USD

Brand Name : KINGTECH

Model Number : KT-300R

Certification : CE,RCC,UL

Place of Origin : China

MOQ : 1PCS

Price : Negotiable

Payment Terms : T/T, LC

Supply Ability : 500,000.00pcs

Delivery Time : 30days

Packaging Details : Standard factory package

Contact Now

Cep Wifi Router Fdd Tdd Lte Wcdma Gsm Global Unlock

4G Indoor Customer Premise Equipment (CPE) provides superior wireless access

performance and comprehensive routing capabilities to bring wireless broadband data and voice

services to end-users. It converts high-speed TDD/FDD signals to Wi-Fi signals on the local

area network (LAN). Wireless and wired devices, including mobile phones, laptops, tablets, and

other smart devices, can access the CPE simultaneously.

1. Basic Specifications

Item	Description
USIM Slot	1.8V/3.0V USIM 2FF
Ethernet Port	RJ45×1, LAN, 10/100 auto-sensing, auto-MDX

Voice Port	RJ11×1
USB Port	USB 2.0×1
Power Supply	Input: Universal range 100V~240V AC Output: 12V DC/1A
Reset Button	Tactile button. Long press over 10s to restore the factory settings
WPS Button	WPS Button ×1
LED Indicators	Power LED×1 WPS/WLAN LED×1 LAN LED×1 LTE Internet LED×1 Signal LED×3
Dimensions	120mm (H) x 150mm (W) x 50mm (D)
Weight	About 170 g

4G/3G/2G Technical Specifications

Wireless Access Technology

TD-LTE/FDD/WCDMA/TD-SCDMA/GSM/GPRS/EDGE/EGPRS

Bands(Max)

CE11S-EE/CE11S-IE: FDD:B1/B2/B3/B5/B7/B8/B20 TDD:B34/B38/B39/B40/B41 TDS:B34/B39 WCDMA:B1/B2/B5/B8 GSM:850/900/1800/1900

CE11S-EA/CE11S-IA: FDD:B2/B3/B4/B5/B7/B8/B28A/B28B/B66 WCDMA:B2/B4/B5/B8 GSM:850/900/1800/1900

CE11S-EP/CE11S-IP: FDD:B1/B2/B3/B5/B7/B8/B28A/28B TDD:B38/B39/B40/B41 TDS:B34/B39 WCDMA:B1/B2/B5/B8

GSM:850/900/1800/1900

Data Rate

LTE FDD:Max 150Mbps(DL)/ Max 50Mbps(UL)； LTE TDD:Max 130Mbps(DL)/ Min 35Mbps(UL)； WCDMA:Max 21Mbps(DL)/ Max 5.76Mbps(UL)； TD-SCDMA:Max 4.2Mbps(DL)/ Max 2.2Mbps(UL)； EDGE: Max 236.8kbps(DL)/ Max 118kbps(UL)；

GPRS: Max 85.6kbps(DL)/ Max 85.6kbps(UL)； GSM: Max 9.6kbps (DL)/ Max 2.7kbps (UL)；

Receive Sensitivity	Compliance with 3GPP standard
MAX Output Power	LTE FDD:23dBm±2dB； LTE TDD:23dBm±2dB； WCDMA:24dBm+1dB/-3dB； TD-SCDMA:24dBm+1dB/-3dB； GSM B5/8: +33 ±2dBm(Power class 4)； GSM B2/3: +30 ±2dBm(Power class 1)；
Antenna Type	Internal Antenna/External Antenna
Antenna Gain	2~3dBi(Internal Antenna) 3~5dBi(External Antenna)

3. WiFi Specifications

Item	Description
Standard	IEEE 802.11b/g/n
Channel Bandwidth	20MHz,40MHz
Frequency	2.4G
TXRX	2T2R
MIMO	DL:2X2
Peak Rate	802.11b:11Mbps 802.11g:54Mbps 802.11n:300Mbps
Modulation	DSSS/CCK,OFDM
Receive Sensitivity	-85dBm in 802.11b -70dBm in 802.11g -66dBm in 802.11n
MAX Output Power	17dBm in 802.11b 14dBm in 802.11g 13dBm in 802.11n
Antenna Type	Internal Antenna
Antenna Gain	1.5~2dBi
Active User	32

4. SW Specifications

	Item	Description
	Language Support	Default English, other languages can be customized upon request
	IP Protocol	IPv4/IPv6

	Voice	VOLTE/CSFB
	SIM Management	PIN Management, SIM Lock
	Network Connection Management	Auto/Manual
	LTE Scan Mode	Full band scan , Frequency Lock ,PCI Lock
	WLAN	Configuration, WPS
	VPN	L2TP PPTP
	NAT	Port forwarding DMZ
	Firewall	IP/MAC/URL Filter Access Control SYN Flood TCP port scan Death of Ping
	Network Management	TR069
	Diagnostics	TCP Dump Ping Trace route
	Statistics	LTE Status Connection Time System Up Time Device Status DHCP Client List WiFi Station List LTE Status Firewall Status
	Maintenance	Date & Time setting Reboot Restore factory settings Restore / Back up configuration file Firmware upgrade locally/OTA (over the air)
	System Log	Operating Log Run-time Log Filter/Select/Display/Export Log

20MHz 40MHz CPE WiFi Router CPE 4G Wireless Router Wan / Lan Port

5. Environmental Specifications

Item	Description
Operating Temperature	-20℃ ~ 60℃
Storage Temperature	-25℃ ~ 70℃
Operating Humidity	5% ~ 95%

20MHz 40MHz CPE WiFi Router CPE 4G Wireless Router Wan / Lan Port

WHAT IS IN PACKAGE

4G LTE WiFi router (CPE) x 1
12V power adaptor x 1
manual book x 1
network cable x 1
gift box 1
